ASTM B163 / ASME SB163 UNS N08825 / DIN 2.4858 / INCOLOY 825 NICKEL ALLOY SEAMLESS TUBE

  • ASTM B163 / ASME SB163 UNS N08825 / DIN 2.4858 / INCOLOY 825 NICKEL ALLOY SEAMLESS TUBE
Place of Origin CHINA
Brand Name Shangle
Certification PED,IS09001
Model Number 12.7
Minimum Order Quantity Negotiable
Price Negotiable
Packaging Details Woven Packing
Delivery Time 30DAYS
Payment Terms L/C, T/T
Supply Ability 500TONS/30DAYS

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material 304 ,304L 310 321 316 316L Standard AISI, ASTM, DIN, EN, GB
Shape SCH10, SCH20, SCH30, STD, SCH40, SCH60, SCH80 Technique Cold Draw
Application Oil, Petroleum/Power Package Woven Packing
Highlight

ASME SB163 NICKEL ALLOY SEAMLESS TUBE

,

DIN 2.4858 NICKEL ALLOY SEAMLESS TUBE

,

ASTM B163 NICKEL ALLOY SEAMLESS TUBE
Leave a Message
Product Description

ASTM B163/ASME SB163 UNS NO8825/DIN 2.4858/INCOLOY 825 NICKEL ALLOY SEAMLESS TUBE





Overview:



Incoloy 825 is a nickel-iron-chromium alloy that offers excellent corrosion resistance in acidic and oxidizing environments. It also provides good resistance to stress-corrosion cracking and pitting. Incoloy 825 is often used in chemical processing, oil and gas production, and marine environments.



Incoloy 825 seamless tubes are highly resistant to corrosion in aggressive environments, such as those containing sulfuric or phosphoric acid, as well as in seawater and brine. The tubes offer excellent mechanical properties, including high strength and toughness.



The seamless tubes are produced using advanced extrusion processes that ensure uniform wall thickness, high dimensional accuracy, and excellent surface finish. The manufacturing process supports the production of tubes in various sizes, thicknesses, and shapes, with precise tolerances.



The tubes are suitable for use in high-pressure and high-temperature applications, such as heat exchangers, condensers, and pressure vessels due to their excellent resistance to corrosion and oxidation at high temperatures.



Incoloy 825 seamless tubes can be used in many different environments, including those with oxidizing and reducing acids and chlorine solutions. They are also suitable for use in harsh environments that can cause stress-corrosion cracking.



The tubes exhibit excellent resistance to impact and thermal fatigue, making them ideal for use in harsh operating conditions where there are frequent temperature changes and vibrations.



Specification:



Specifications ASTM B163 & Its equivalent ASME, DIN & EN Standard
Grades UNS N08825/DIN 2.4858/INCOLOY 825
Type U-bend / Straight seamless tube
Outside Diameter 1/4'' to 2'' or custom size
Wall Thickness BWG25;BWG22;BWG20;BWG18;BWG16;BWG14;BWG12;BWG10
Length Upto 6 meters, custom cut lengths
Delivery Condition Solution Annealed & Pickled
Ends Plain End, Beveled End
Other Testing Product Analysis, Eddy Current Test, Hydrostatic Test, Ultrasonic Test, Flattening Test, Hardness Test, Tensile Test etc.
Dimension All Pipes & Tube Is Manufactured and Inspected / Tested to the Relevant standards including ASTM and ASME
Packing Plywood case/Woven bag in bundle



Chemical Composition:

Grade Ni Cu Mo Fe Mn C Si S Cr Al Ti
UNS N08825 38.0-46.0 1.5-3.0 2.5-3.5 22.0 min. 1.0 max. 0.05 max. 0.50 max. 0.03 max. 19.5-23.5 0.2 max. 0.6-1.2



Mechanical Properties:

Grade Tensile Strength, min, ksi (MPa)

Yield Strength,

min, ksi (MPa)

Elongation in 2 in.

or 50mm, min (%)
UNS N08825 85(586) 35(241) 30



Applications:



1.Sulphuric acid piping and vessels

2.Phosphoric acid evaporators

3.Pickling tank heaters, pickling tanks and equipment

4.Chemical process equipment

5.Propellor shafts

6.Tank trucks

7.Calorifiers

8.Electrostatic precipitator electrodes

9.Hot vessels for food, water and seawater,

10.ammonium sulphate vessels

11.Expansion bellows

12.Marine exhaust systems

13.Power station ash hoppers

14.Ethylene furnace quench boilersHydrocarbon cracking Valves, fittings and other components exposed to corrosive attack from 1100-1800° F

15.Industrial furnaces

16.Heat-treating equipment

17.Chemical and petrochemical processing

18.Super-heater and re-heaters in power plants

19.Pressure vessels

20.Heat exchanger
