ASTM B338 Grade 7 / UNS R52400 Seamless Titanium Alloy Tube Heat Exchanger Tube

  • ASTM B338 Grade 7 / UNS R52400 Seamless Titanium Alloy Tube Heat Exchanger Tube
Place of Origin CHINA
Brand Name Shangle
Certification PED,IS09001
Model Number 12.7
Minimum Order Quantity Negotiable
Price Negotiable
Packaging Details Woven Packing
Delivery Time 30DAYS
Payment Terms L/C, T/T
Supply Ability 500TONS/30DAYS

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material 304 ,304L 310 321 316 316L Standard AISI, ASTM, DIN, EN, GB
Shape SCH10, SCH20, SCH30, STD, SCH40, SCH60, SCH80 Technique Cold Draw
Application Oil, Petroleum/Power Package Woven Packing
Highlight

UNS R52400 Seamless Titanium Alloy Tube

,

ASTM B338 Seamless Titanium Alloy Tube
Leave a Message
Product Description

ASTM B338 / ASME SB338 Titanium Tube Grade 7 UNS R52400 Alloy Steel Seamless Tube





Titanium Grade 7, also known as Ti-0.15Pd (Titanium 0.15% Palladium), is a highly corrosion-resistant and weldable grade of titanium. It is part of the commercially pure titanium group and is alloyed with a small amount of palladium (approximately 0.12-0.25%) to enhance its corrosion resistance. Its corrosion resistant alpha titanium alloy with similar mechanical properties to the commercially pure grades. It has a small palladium addition to improve corrosion resistance, particularly in mineral acids and strong brines.





The Feature of Titanium Gr.7

  1. Corrosion Resistance: Titanium Grade 7 is renowned for its exceptional corrosion resistance, especially in reducing and mildly oxidizing environments. It is particularly well-suited for applications in chemical processing, where it can withstand exposure to various corrosive chemicals and acids.

  2. Strength: Like other commercially pure titanium grades, Titanium Grade 7 offers a good balance of strength and ductility. Its mechanical properties make it suitable for a wide range of applications, particularly in the chemical industry.

  3. Weldability: Titanium Grade 7 is known for its excellent weldability. It can be easily welded using various common methods, such as gas tungsten arc welding (GTAW) and gas metal arc welding (GMAW). This makes it a preferred choice for fabrications that require welding.

  4. Fabrication: This titanium grade can be easily formed, machined, and fabricated into various shapes and components. It is commonly used in the manufacture of heat exchangers, valves, and other equipment in the chemical and petrochemical industries.





Specification

ASTM B338 Titanium Alloy Tubes Specification ASTM B338 / ASTM B861 / ASTM B862 / ASME SB338 / ASME SB861 / ASME SB862
ASTM B338 Titanium Alloy Tubes Grades Grade 1 , Grade 2, Grade 3 , Grade 5 , Grade 7, Grade 8, Grade 9, Grade 11, Grade 12, Grade 23, UNS R50250, UNS R50400, UNS R56400, UNS R52400, UNS R56320, UNS R53400, Ti-6Al-4V, C-130AM, C-110M, Ti-4Al-3Mo-1V, Ti-6Al-2Sn-4Zr-2Mo, Ti-8Al-1Mo-1V, Ti-13V-11Cr-3Al, Ti-15V-3Cr-3Sn-3Al
ASTM B338 Titanium Alloy Tubes Type Hot Rolled / Cold Drawn / Welded / ERW
ASTM B338 Titanium Alloy Tubes Outer Diameter Size Seamless - 1/4"NB to 12"NB (Nominal Bore Size)
Welded / ERW- 1"NB to 16"NB (Nominal Bore Size)
ASTM B338 Titanium Alloy Tubes Wall Thickness Schedule 10 to Schedule 160
ASTM B338 Titanium Alloy Tubes Length 5 to 7 Meters, 09 to 13 Meters, Single Random Length, Double Random Length And Customize Size.
ASTM B338 Titanium Alloy Tubes Pipe Ends Plain Ends / Beveled Ends
ASTM B338 Titanium Alloy Tubes Delivery Conditions As Rolled, Cold Drawn, Hot Finish, Stress Relieved, Annealed, Hardened, Tempered
ASTM B338 Titanium Alloy Tubes Coating Electropolish, Mechanical Polish, Satin Finish, Passivated
ASTM B338 Titanium Alloy Tubes Other Testing ardness Test, Hydrostatic Test, Eddy Current test, Eddy Current, Tensile Test, Flattening, Flare Test, Annealed, Hydrostatic Test, Tempered, Stress Relieved etc.
ASTM B338 Titanium Alloy Tubes Dimension All Pipes Is Manufactured and Inspected / Tested to the Relevant standards including ASTM And ASME
ASTM B338 Titanium Alloy Tubes Value Added Services Draw / Expansion / Machining / Sand Blasting / Shot Blasting / Heat Treatment
ASTM B338 Titanium Alloy Tubes Packaging Loose / Bundle / Wooden Pallet / Wooden Box / Plastic Cloth Wraps / Plastic End Caps / Beveled Protector
ASTM B338 Titanium Alloy Tubes Material Test Certificate Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS ETC




Chemical Composition of Titanium Alloy Tubing

Element Chemical Composition %
Grade 1 Grade 2 Grade 3 Grade 5 Grade 7 Grade 9 Grade 11 Grade 12 Grade 23
Nitrogen, max 0.03 0.03 0.05 0.05 0.03 0.03 0.03 0.03 0.03
Carbon, max 0.08 0.08 0.08 0.08 0.08 0.08 0.08 0.08 0.08
Hydrogen, max 0.015 0.015 0.015 0.015 0.015 0.015 0.015 0.015 0.0125
Iron, max 0.20 0.30 0.30 0.40 0.30 0.25 0.20 0.30 0.25
Oxygen, max 0.18 0.25 0.35 0.20 0.25 0.15 0.18 0.25 0.13
Aluminum … … … 5.5-6.75 … 2.5-3.5 … … 5.5-6.5
Vanadium … … … 3.5-4.5 … 2.0-3.0 … … 3.5-4.5
Tin … … … … … … … … …
Ruthenium … … … … … … … … …
Palladium … … … … 0.12-0.25 … 0.12-0.25 … …
Molybdenum … … … … … … … 0.2-0.4 …
Chromium … … … … … … … … …
Nickel … … … … … … … 0.6-0.9 …
Niobium … … … … … … … … …
Ziconium … … … … … … … … …
Silicon … … … … … … … … …
Residuals, max each 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1
Residuals, max total 0.4 0.4 0.4 0.4 0.4 0.4 0.4 0.4 0.4
Titanium balance balance balance balance balance balance balance balance balance




Mechanical Properties of Titanium Alloy Tubing

Grade Tensile Strength, min Yield Strength (0.2% Offset) Elongation 2 in. or 50 mm
  min max
Ksi (Mpa) Ksi (Mpa) Ksi (Mpa) gage length min %
Grade 1 35 (240) 25 (170) 45 (310) 24
Grade 2 50 (345) 40 (275) 65 (450) 20
Grade 3 65 (450) 55 (380) 80 (550) 18
Grade 5 130 (895) 120 (828) … … 10
Grade 7 50 (345) 40 (275) 65 (450) 20
Grade 9 90 (620) 70 (483) 45 … 15
Grade 11 35 (240) 25 (170) … (310) 24
Grade 12 70 (483) 50 (345) … … 18
Grade 23 120 (828) 110 (759) … … 10





ASTM B338 Grade 7 Titanium Alloy Tubes Applications

  • Chlorination systems
  • Flue gas scrubbers
  • Outlet ducting and stack liners for power plants, pulp and paper bleach plants, sulfur dioxide scrubbers, and weld overlay of less corrosion resistant metals
  • Acid production and pickling systems
  • Pharmaceutical industries use alloy fittings and tubing to avoid contamination caused by corrosion related failures
  • Cellophane manufacturing
  • Chlorination systems
  • Pesticide production
  • Incineration scrubber systems
  • Chemical process industry in equipment like flue gas scrubbers, chlorination systems, sulfur dioxide scrubbers, pulp and paper bleach plants, pickling systems, and nuclear fuel reprocessing
  • Waste water processing
  • Pollution control stack liners, ducts, dampers, scrubbers, stack-gas reheaters, fans and fan housings
  • Flue gas desulfurization systems
  • Chemical processing components like heat exchangers, reaction vessels, evaporators, and transfer piping
  • Sour gas wells
  • Pulp and paper production
  • Waste treatment
  • Pharmaceutical and food processing equipment
  • ASTM B338 Grade 7 / UNS R52400 Seamless Titanium Alloy Tube Heat Exchanger Tube 0
