ASTM A312 (ASME SA312) TP310S SS Corrugated Tubes For Heat Exchanger

  • ASTM A312 (ASME SA312) TP310S SS Corrugated Tubes For Heat Exchanger
Place of Origin CHINA
Brand Name Shangle
Certification PED,IS09001
Model Number 12.7
Minimum Order Quantity Negotiable
Price Negotiable
Packaging Details Woven Packing
Delivery Time 30DAYS
Payment Terms L/C, T/T
Supply Ability 500TONS/30DAYS

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material 304 ,304L 310 321 316 316L Standard AISI, ASTM, DIN, EN, GB
Shape SCH10, SCH20, SCH30, STD, SCH40, SCH60, SCH80 Technique Cold Draw
Application Oil, Petroleum/Power Package Woven Packing
Highlight

TP310S SS Corrugated Tubes

,

ASTM A312 SS Corrugated Tubes

,

Heat Exchanger ASME SA312 Tubes
Leave a Message
Product Description
echnique: Cold Rolled Hot Rolled Application: Construction,Heat Exchanger,oil And Gas,Industry,boiler




ASTM A312 (ASME SA312) TP310S SS Corrugated Tubes For Heat Exchanger



Description



Stainless Steel Corrugated Tube is tube made of stainless steel with corrugation on the inside or outside.

Stainless Steel Corrugated Tube is a type of tube with corrugations which allow the tube to be bent and change direction of flow without having to make more connections through welding. Thus there will be no leak through the bends.



Stainless Steel Seamless (SMLS) pipe is formed by drawing a solid billet over a piercing rod to create the hollow shell. As the manufacturing process does not include any welding, Seamless Pipes are perceived to be stronger and more reliable. Historically, seamless pipe was regarded as withstanding pressure better than other types, and was often more available than Welded Pipe.

Grade 310, combining excellent high temperature properties with good ductility and weldability, is designed for high temperature service. It resists oxidation in continuous service at temperatures up to 1150°C provided reducing sulphur gases are not present. It is also used for intermittent service at temperatures up to 1040°C.

Grade 310S (UNS S31008) is used when the application environment involves moist corrodents in a temperature range lower than that which is normally considered "high temperature" service. The lower carbon content of 310S does reduce its high temperature strength compared to 310.

Like other austenitic grades these have excellent toughness, even down to cryogenic temperatures, although other grades are normally used in this environment.

Grade 310L (and proprietary versions of this grade), is a 0.03% maximum carbon version of 310, sometimes used for very specific corrosive environments, such as urea production



Chemical Composition Of ASTM A312 TP 310 Stainless Steel Seamless Pipe


Chemical Composition 310 310S
Carbon 0.25 max 0.08 max
Manganese 2.00 max 2.00 max
Silicon 1.50 max 1.50 max
Phosphorus 0.045 max 0.045 max
Sulphur 0.030 max 0.030 max
Chromium 24.00 - 26.00 24.00 - 26.00
Nickel 19.00 - 22.00 19.00 - 22.00



Mechanical Properties Of ASTM A312 TP 310 Stainless Steel Seamless Pipe


Mechanical Properties 310/ 310S
Grade 0.2 % Proof Stress MPa (min) 205
Tensile Strength MPa (min) 520
Elongation % (min) 40
Hardness (HV) (max) 225



Physical Properties Of ASTM A312 TP 310 Stainless Steel Seamless Pipe


Properties at Value Unit
Density   8,000 Kg/m3
Electrical Conductivity 25°C 1.25 %IACS
Electrical Resistivity 25°C 0.78 Micro ohm.m
Modulus of Elasticity 20°C 200 GPa
Shear Modulus 20°C 77 GPa
Poisson's Ratio 20°C 0.30
Melting Rnage   1400-1450 °C
Specific Heat   500 J/kg.°C
Relative Magnetic Permeability   1.02
Thermal Conductivity 100°C 14.2 W/m.°C
Coefficient of Expansion 0-100°C 15.9 /°C
  0-315°C 16.2 /°C
  0-540°C 17.0 /°C



Grade Specifications For 310 Stainless Steel Pipes


STAINLESS STEEL SS 310
AISI
310
UNS
S31000
Werkstoff Nr.
1.484


ASTM A312 (ASME SA312) TP310S SS Corrugated Tubes For Heat Exchanger 0
