ASTM A213 / ASME SA213 Stainless Steel 304 Seamless Bright Annealed Tube

  • ASTM A213 / ASME SA213 Stainless Steel 304 Seamless Bright Annealed Tube
Place of Origin CHINA
Brand Name Shangle
Certification PED,IS09001
Model Number 12.7
Minimum Order Quantity Negotiable
Price Negotiable
Packaging Details Woven Packing
Delivery Time 30DAYS
Payment Terms L/C, T/T
Supply Ability 500TONS/30DAYS

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material 304 ,304L 310 321 316 316L Standard AISI, ASTM, DIN, EN, GB
Shape SCH10, SCH20, SCH30, STD, SCH40, SCH60, SCH80 Technique Cold Draw
Application Oil, Petroleum/Power Package Woven Packing
Highlight

304 Seamless Bright Annealed Tube

,

ASTM A213 Seamless Bright Annealed Tube

,

ASME SA213 Seamless Bright Annealed Tube
Leave a Message
Product Description

ASTM A213 / ASME SA213 Stainless Steel 304 Seamless Bright Annealed Tube





Most stainless steel tubing is heat treated by the bright annealing process, in which the tubing is annealed in a protective medium to prevent discoloration of the bright surface. Since austenitic stainless steel is the most often used tubing material, the heat treatment process is bright annealing of austenitic stainless steel in essence.



Stainless steel pipe and tubing are used for a variety of reasons: to resist corrosion and oxidation, to resist high temperatures, for cleanliness and low maintenance costs, and to maintain the purity of materials which come In contact with stainless.





SS304 Seamless Bright Annealed Tube Mechanical Properties

SS GRADE HEAT TREATMENT TEMPERURE F (C) MINIMUM HARDNESS
BRINELL ROCKWELL
TP304 Solution 1900 (1040) 192HBW/ 200HV 90HRB
TP304L Solution 1900 (1040) 192HBW/ 200HV 90HRB
TP316 Solution 1900(1040) 192HBW/ 200HV 90HRB
TP316L Solution 1900(1040) 192HBW/ 200HV 90HRB
TP321 Solution 1900(1040) F 192HBW/ 200HV 90HRB
TP347 Solution 1900(1040) 192HBW/ 200HV 90HRB





SS304 Seamless Bright Annealed Tube Chemical Composition

SS GRADE ASTM A269/SA 269 CHEMICAL COMPOSITION % MAXIMUM
C MN P S SI CR NI MO N B NB TI
TP304 0.08 2.00 0.045 0.030 1.00 18.0-20.0 8.0-11.0 --- --- --- ---
TP304L 0.035 2.00 0.045 0.030 1.00 18.0-20.0 8.0-12.0 --- --- --- ---
TP316 0.08 2.00 0.045 0.030 1.00 16.0-18.0 10.0-14.0 2.00-3.00 --- --- ---
TP316L 0.035 D 2.00 0.045 0.030 1.00 16.0-18.0 10.0-15.0 2.00-3.00 --- --- ---
TP321 0.08 2.00 0.045 0.030 1.00 17.0-19.0 9.0-12.0 --- --- --- 5C -0.70
TP347 0.08 2.00 0.045 0.030 1.00 17.0-19.0 9.0-12.0     10C -1.10 ---





ASTM A213/ASME SA213 Size Tolerance

A thickness tolerance-hot roll(HR)-A213
外径范围 Type Wall Thickness Tolerance
OD Range Average Min.
1 6~65mm(Incl.) SMLS &WLD (-12.5%,+20%)
2 >65mm SMLS &WLD t/D<=5% (-12.5%,+22.5%)
3 >65mm SMLS &WLD t/D>5% (-12.5%,+15%)

B thickness tolerance-hot roll(HR)-ASTM A1016
外径范围 Type Wall Thickness Tolerance
OD Range Average Min.
1 0~12.7mm(Incl.) SMLS &WLD   (0,+30%)
2 12.7~38.1mm(Incl.) SMLS &WLD   (0,+20%)
3 38.1~88.9mm(Incl.) SMLS &WLD   (0,+20%)
3 88.9~139.7mm(Incl.) SMLS &WLD   (0,+20%)
4 139.7~203.2mm(Incl.) SMLS &WLD   (0,+20%)

C thickness tolerance-cold roll(CR)-A1016
外径范围 Type Wall Thickness Tolerance
OD Range Under (-) Over(+)
1 0~38.1mm(Incl.) SMLS 0 20%
2 >38.1mm SMLS 0 22%
3 All Sizes WLD 0 18%
Average wall thickness tolerance shall be (-/+10 )%

D outside diameter tolerance-cold roll(CR)-A1016
外径范围 Type Wall Thickness Tolerance
OD Range Under (-) Over(+)
1 0~25mm(Incl.) SMLS & WLD 0.11mm 0.1mm
2 25~40mm(Incl.) SMLS & WLD 0.15mm 0.15mm
3 40~50mm(Incl.) SMLS & WLD 0.2mm 0.2mm
4 50~65mm(Incl.) SMLS & WLD 0.25mm 0.25mm
5 65~75mm(Incl.) SMLS & WLD 0.3mm 0.3mm
6 75~100mm(Incl.) SMLS & WLD 0.38mm 0.38mm
7 100~200mm(Incl.) SMLS & WLD 0.64mm 0.38mm
8 200~225mm(Incl.) SMLS & WLD 1.14mm 0.38mm

E outside diameter tolerance-heat roll(HR)-A1016
外径范围 Type Wall Thickness Tolerance
OD Range Under (-) Over(+)
1 0~100mm(Incl.) SMLS 0.4mm 0.4mm
2 100~200mm(Incl.) SMLS 1.2mm 0.4mm
3 200~225mm(Incl.) SMLS 1.6mm 0.4mm

F 长度公差范围-A1016
Length Tolerance
Range(m) TYPE OD range Tolerance
1 0~24ft(7.3m Incl.) SMLS +Hot Finished All Sizes 0,+5mm
2 0~24ft(7.3m Incl.) SMLS +Cold Finished <50.8mm 0,+3mm
3 0~24ft(7.3m Incl.) SMLS +Cold Finished 50.8mm(Incl.) to Up 0,+5mm


If length >7.3m, each 10ft(3m) add 3mm , If the length >24ft , tolerence (0,+13mm)

G 直度公差范围-A1016
Straightness Tolerance
Range(m) Thickness Range Maximum Curvature in
any 3 ft (Inch)		 Maximum Curvature
in Total Length(Inch)
1 Up to 5" (Incl.) Over 3% of OD to 0.5" 0.03Inch 0.01 X Length Ft
2 5" ~ 8" (Incl.) Over 4% of OD to 0.75" 0.045Inch 0.015 X Length Ft
3 8" ~ 12.75" (Incl.) Over 4% of OD to 1.0" 0.060Inch 0.020 X Length Ft





Application

Chemical and petrochemical

Power generation

Renewable energy

Pulp and Paper

Process piping

Pharmaceutical

Food and beverage

Oil and gas

Mining

Water/waste

Marine Industry

or Fertilizers
