ASTM A269 TP316L Stainless Coil Tubing For Fluid Industry

  • ASTM A269 TP316L Stainless Coil Tubing For Fluid Industry
Place of Origin CHINA
Brand Name Shangle
Certification PED,IS09001
Model Number 12.7
Minimum Order Quantity Negotiable
Price Negotiable
Packaging Details Woven Packing
Delivery Time 30DAYS
Payment Terms L/C, T/T
Supply Ability 500TONS/30DAYS

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material 304 ,304L 310 321 316 316L Standard AISI, ASTM, DIN, EN, GB
Shape SCH10, SCH20, SCH30, STD, SCH40, SCH60, SCH80 Technique Cold Draw
Application Oil, Petroleum/Power Package Woven Packing
Highlight

TP316L Stainless Coil Tubing

,

Fluid Industry Stainless Coil Tubing

,

ASTM A269 Stainless Coil Tubing
Leave a Message
Product Description

Stainless Steel Coil Seamless Tubing, ASTM A269 TP316L, 6.35MM*1.24MM*100M, AVG. Wall thickness




Stainless Steel Coil Tubes:
(1) Commodity name: Austenitic Stainless Steel Coil Tubes
(2) Process method: cold drawn/cold pilgered
(3) Material: TP304, TP304L,TP316L,dual grade 317L , 316Ti, TP321

(4) Standard: ASTM ( ASME) ,EN, DIN, JIS and etc.
(5) Specifications:a) O.D.:1/4" -3/4"
b) W.T.:0.028"- 0.065"
c) Length:customized, max:1000m/pc.
(6) Delivery conditions: annealed & pickled
(7) Applications: widely used in petrol, chemical, pharmacy, foodstuff, machinery, spaceflight, war industry.

(8) boiler gas, hot water heating parts, hardware, shipping, power and other industries.
(9) Packing: packed by weaving bags, then protected by seaworthy wooden case.



Material Grade:

American Standard Austenitic Steel:
TP304,TP304L,TP304H, TP304N, TP310S,TP316L,TP316Ti,TP316H, TP317,TP317L, TP321, TP321H,TP347, TP347H,904L…
Duplex Steel :
S32101,S32205,S31803,S32304,S32750, S32760
Others:TP405,TP409, TP410, TP430, TP439,...
Europen Standard 1.4301,1.4307,1.4948,1.4541,1.4878,1.4550,1.4404,1.4571,1.4438, 1.4841,1.4845,1.4539,1.4162, 1.4462, 1.4362, 1.4410, 1.4501
GOST 08Х17Т,08Х13,12Х13,12Х17,15Х25Т,04Х18Н10,08Х20Н14С2, 08Х18Н12Б,10Х17Н13М2Т,08Х18Н10,08Х18Н10Т, 08Х18Н12Т,08Х17Н15М3Т,12Х18Н10Т,12Х18Н12Т,12Х18Н9,
17Х18Н9, 08Х22Н6Т, 06ХН28МДТ


• Diameter from 3mm (0.118”) to 25.4mm (1.00”) OD.
• Wall thickness from 0.5mm (0.020”) to 3mm (0.118”).
• OD tolerance +/- 0.005” (0.13mm) and +/- 10% wall thickness. Other tolerances are available on request.
• Coil lengths up to 1500m (5,000ft) without orbital joints depending on product dimensions.
• Coil lengths up to 13,500m (45,000ft) with orbital joints.
• Encapsulated, PVC coated or bare line tubing.
• Available on wooden or steel spools.

Imperial size Metric size
OD
inch		 WT
inch		 OD
mm		 WT
mm
1/8 (0.125) 0.028 3.18 0.71
  0.035 3.18 0.89
3/16 (0.188) 0.028 4.76 0.71
  0.035 4.76 0.89
  0.049 4.76 1.24
1/4 (0.250) 0.035 6.35 0.89
  0.049 6.35 1.24
  0.065 6.35 1.65
  0.083 6.35 2.11
3/8 (0.375) 0.035 9.53 0.89
  0.049 9.53 1.24
  0.065 9.53 1.65
  0.083 9.53 2.11
1/2 (0.500) 0.035 12.7 0.89
  0.049 12.7 1.24
  0.065 12.7 1.65
  0.083 12.7 2.11


The quality of our products for the control line in oil and gas sector is assured not just during the controlled manufacturing process but also by way of finished product testing. Typical tests include:
• Non-destructive tests
• Hydrostatic tests
• Surface finish controls
• Dimensional accuracy measurements
• Flare and coning tests
• Mechanical and chemical property testing
