ASTM A269 TP316L 1.4404 Stainless Steel SMLS Bright Annealed Tube

  • ASTM A269 TP316L 1.4404 Stainless Steel SMLS Bright Annealed Tube
Place of Origin CHINA
Brand Name Shangle
Certification PED,IS09001
Model Number 12.7
Minimum Order Quantity Negotiable
Price Negotiable
Packaging Details Woven Packing
Delivery Time 30DAYS
Payment Terms L/C, T/T
Supply Ability 500TONS/30DAYS

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material 304 ,304L 310 321 316 316L Standard AISI, ASTM, DIN, EN, GB
Shape SCH10, SCH20, SCH30, STD, SCH40, SCH60, SCH80 Technique Cold Draw
Application Oil, Petroleum/Power Package Woven Packing
Highlight

1.4404 Stainless Steel SMLS Tube
Leave a Message
Product Description

ASTM A269 TP316L 1.4404 Stainless Steel SMLS Bright Annealed Tube





ASTM A269 Tp316L is a grade of seamless and welded austenitic steel with nominal wall thickness that is designed with 316 austenitic stainless steel. The ASTM A269 TP316L Tube is composed of an outstanding content of chromium, nickel, and molybdenum. The content embedded with these modules gives them excellent corrosion and oxidation resistance properties.



1. Process Method: Cold Drawn, Cold Rolled
2. Surface Finish: Bright Annealed
3. Materials: TP304/L/H; TP316/L/Ti; TP309S; TP310S; TP321/H; TP317L; TP347/H, etc
4. Ends: Beveled or Plain





Our range of Austenitic Stainless Steel 316 / 316L Bright Annealed Tubes is in conformation with the international quality standards and is thoroughly tested on various parameters before delivering to the clients. Designed according to the national and international standards, this Stainless Steel Bright Annealed Tubing is offered in made-to-order length sizes and shapes to our well-regarded customers.



Chemical Composition:



GRADE



C

MN

SI

P

S

CR

MO

NI

N
316L Min - - - - - 16.0 2.00 10.0 -
Max 0.03 2.0 0.75 0.045 0.03 18.0 3.00 14.0 0.10





Mechanical Properties:



GRADE TENSILE STR
(MPA) MIN		 YIELD STR
0.2% PROOF
(MPA) MIN		 ELONG
(% IN 50MM) MIN		 HARDNESS
ROCKWELL B (HR B) MAX BRINELL (HB) MAX
316L
485
170
40
95
217





Physical Properties:


GRADE DENSITY
(kg/m³)		 ELASTIC MODULUS
(GPA)		 MEAN CO-EFF OF THERMAL EXPANSION (ΜM/M/°C) THERMAL CONDUCTIVITY
(W/M.K)		 SPECIFIC HEAT 0-100°C
(J/KG.K)		 ELEC RESISTIVITY
(NΩ.M)
0-100°C 0-315°C 0-538°C AT 100°C AT 500°C
316L 8000 193 15.9 16.2 17.5 16.3 21.5 500 74



Equivalent Material:

GRADE UNS
NO		 OLD BRITISH EURONORM SWEDISH
SS		 JAPANESE
JIS
BS EN NO NAME
316L
S31603
316S11
-
1.4404
X2CrNiMo17-12-2
2348
SUS 316L





Applications:



-Chemical and petrochemical

-Power generation

-Renewable energy

-Pulp and Paper

-Process piping

-Pharmaceutical

-Food and beverage

-Oil and gas

-Mining

-Water/waste

-Marine Industry

-Fertilizers
