Bright Annealed Tube Seamless Stainless Steel Tube/pipe TP304L TP316L BA Tube Sanitary

Bright Annealed Seamless Stainless Steel pipe/tube TP304L TP316L

Characteristic

BA Tube is Bright Annealed Tubing available in a wide range of stainless steel tubing, are characterized by tight tolerances, and the inside surface of the tubes is free of oil, grease and other particles. This ensures, for example, an optimized and even flow of liquids and gases from the sensor to the measuring instrument.

We have 4 Sets of three roller Precision Cold Rolling Machines using highly polished rollers in touch with the stainless steel surface and control the velocity of the pilger machine to ensure the smoothness and brightness. Selected the best quality stainless steel round bar, clean and smooth on outside surface and inside surface.

Withstand high pressure,no deformation after cold bending, no crack and break after flattening and flaring etc.

Shangle Steel have a complete line of ASTM A269 TP304L Stainless Steel Seamless Pipe and supply ASTM A269 TP304L Stainless Steel Welded Pipe Austenitic Chromium Nickel Stainless Steel Pipe for corrosive or high temperature service, or both, or for general applications.

We supply ASTM A269 TP304L Stainless Steel Seamless Pipe Specification ASME SA / ASTM A249, A268, A269, A270, A554, A688, A778, DIN 17455, DIN 17456, 17457, DIN 17458 [Grade 1] and 202, 304, 304L Grade, 304H, 304LN, 309s, 310s, 316, 316L, 316H, 316Ti, 316LN, 317L, 321, 321H, 347, 347H, 904L, 254SMO, 6MO, 6MOLY, UNS S31254, heat exchange tube, boiler tube, condenser tube, instrument tube, capillaries, etc.

The rating indicates the test method required for a particular application.

Shangle Steel is specialized in ASTM A269 TP304L Stainless Steel Seamless Pipe and has many years of experience in manufacturing ASTM A269 TP304L Stainless Steel Seamless Pipe.

We provide high quality, low cost but best service. Therefore, our export account of ASTM A269 TP 304L Stainless Steel Seamless Pipe today is in different countries like Kuwait, Saudi Arabia, Oman, UAE, Singapore, Malaysia, Indonesia, Korea, Chile, Peru, Venezuela, Australia, Nigeria, Angola, Senegal, Mozambique, Algeria, Libya, Azerbaijan, Netherlands, Brazil, Norway.

BA Tube is Bright Annealed Tubing available in a wide range of stainless steel tubing, are characterized by tight tolerances, and the inside surface of the tubes is free of oil, grease and other particles. This ensures, for example, an optimized and even flow of liquids and gases from the sensor to the measuring instrument.

We have 4 Sets of three roller Precision Cold Rolling Machines using highly polished rollers in touch with the stainless steel surface and control the velocity of the pilger machine to ensure the smoothness and brightness.

Selected the best quality stainless steel round bar, clean and smooth on outside surface and inside surface.

Withstand high pressure,no deformation after cold bending, no crack and break after flattening and flaring etc.

BA Tubes Bright Annealing Tubing

Bright Annealed Tube Technical Data:

1) BA Tube Description:

Bright Annealed Tubes | BA Tube | Bright Annealed Stainless Steel Tubes | Bright Annealed Stainless Steel Tubing

2) BA Tube Specification:

ASTM A213 / A269 / A632

DIN 17458 / ISO 1127

3) BA Tube Reference Sizes:

6.35×0.89, 9.53×0.89, 12.7×1.24, 19.05×1.65, 25.4×2.11, 3/8, 5/8, 1/2, 3/4, 1, 11/4, 11/2, 2

Special sizes can be made to order.

4) BA Tube Advantages:

a. good dimensional accuracy

O.D.: +/-0.05mm, W.T.: +/-0.05mm

b. excellent surface roughness

outside surface: Ra < 0.6um, inside surface: Ra < 0.3um

5) BA Tube Main Production Equipments:

2 sets of Cold Drawing Machine with Floating Mandrel

6 sets of Cold Pilger Machine with Three Roller

2 Sets of Bright Annealed Furnace with Pure H2

Stainless Steel Coil Tubes:
(1)Commodity name: Austenitic Stainless Steel Coil Tubes
(2)Process method: cold drawn/cold pilgered
(3)Material: TP304, TP304L,TP316, TP316L,dual grade 317L , 316Ti, TP321

(4)Standard: ASTM ( ASME) ,EN, DIN, JIS and etc.
(5)Specifications:a) O.D.:1/4" -3/4"
b) W.T.:0.028"- 0.065"
c) Length:customized, max:1000m/pc.
(6)Delivery conditions: annealed & pickled
(7)Applications: widely used in petrol, chemical, pharmacy, foodstuff, machinery, spaceflight,

war industry.

(8)boiler gas, hot water heating parts, hardware, shipping, power and other

industries.
(9)Packing: packed by weaving bags, then protected by seaworthy wooden case.

Material Grade:

Grades:

301, 304, 316, and others as specified by the customer.

Our BA Tube are widely used in the fields of precision instruments, oil & gas service, precise mechanical parts, semiconductor industry, bio-pharmaceutical, etc

Applications/Industries:

Bent and formed stainless steel tubing is used in a variety of applications, including:

• Manifold assemblies for the transportation industry
• Hydraulic fluid supply lines for industrial purposes
• Bumpers to protect OEM products
• Housing for water monitoring systems
• Tubular handles used in OEM instruments and machinery
