ASTM A790 / ASTM A928 UNS S32750 Super Duplex Stainless Steel Pipe

  • ASTM A790 / ASTM A928 UNS S32750 Super Duplex Stainless Steel Pipe
Place of Origin CHINA
Brand Name Shangle
Certification PED,IS09001
Model Number 12.7
Minimum Order Quantity Negotiable
Price Negotiable
Packaging Details Woven Packing
Delivery Time 30DAYS
Payment Terms L/C, T/T
Supply Ability 500TONS/30DAYS

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material 304 ,304L 310 321 316 316L Standard AISI, ASTM, DIN, EN, GB
Shape SCH10, SCH20, SCH30, STD, SCH40, SCH60, SCH80 Technique Cold Draw
Application Oil, Petroleum/Power Package Woven Packing
Highlight

Super Duplex Stainless Steel Pipe

,

ASTM A790 Stainless Steel Pipe

,

UNS S32750 Seamless Stainless Tube
Leave a Message
Product Description

ASTM A790 / ASTM A928 UNS S32750 Super Duplex Stainless Steel Pipe





S32750 Super Duplex Pipe have enhanced pitting and crevice corrosion resistance when compared with 300-series austenitic stainless steel or conventional duplex alloys. This can be attributed to the enhanced levels of chromium, molybdenum and nitrogen found in these materials. Alloy 2507 is the most common “super” duplex grade.





UNS 31803 (F51), UNS 32205 (F60) Alloy 2205, UNS S32550 (F61), UNS S 32750 (F53), Alloy 2507 and UNS 32760 (F55)

Standards: ASTM/ASME A789/SA789, A790/SA790,A450,A530

Material: UNS S31803(Cr22Ni5Mo3/1.4462)/2205,UNS S32750(1.4410),UNS S31500(Cr18NiMo3Si2),

UNS32760(1.4501)




Usage of Duplex 2507 Pipe S32750 Stainless Steel:

It should be limited to applications below 6000 F (3160 C). Extended elevated temperature exposure can reduce both the toughness and corrosion resistance of alloy 2507.The high chromium, molybdenum, and nitrogen levels provide excellent resistance to pitting, crevice, and general corrosion. The duplex structure provides 2507 with exceptional resistance to chloride stress corrosion cracking.

S32750 Super Duplex Pipe possesses excellent mechanical properties. Often a light gauge of S32750 Stainless Steel can be used to achieve the same design strength of a thicker nickel alloy. The resulting saving in weight can reduce the overall cost of fabrication.





Chemical Composition:



Grade

C

max

Si

max

Mn

max

P

max

S

max

 Cr Ni Mo N
UNS S32750 0.030 0.8 1.2 0.030 0.015 24.0-26.0 6.0-8.0 3.0-5.0 0.24-0.32
UNS S31803 0.030 1.0 2.0 0.020 0.020 21.0-23.0 4.5-6.5 2.5-3.5 0.08-0.20
UNS S31500 0.030 1.0 1.2-2.0 0.030 0.030 18.0-19.0 4.5-5.5 2.5-3.5 0.05-0.10





Physical Properties:



Grade Y.S.MPa min T.S.Mpa min Elongation % Hardness HRC
UNS S32750 550 800 15 20
UNS S31803 450 620 25 20
UNS S31500 440 630 30 20





Duplex Stainless Steel Pipe Application:



Chemical processing, Transport and Storage.

Oil and gas exploration and offshore rigs.

Oil and gas refining.

Marine environments.

Pollution control equipment.

Pulp and paper manufacturing

Chemical process Plant
