Super Duplex Steel Buttweld Fittings , 2 Inch Sch80 Butt Weld Equal Tee For Desalination

  • Super Duplex Steel Buttweld Fittings , 2 Inch Sch80 Butt Weld Equal Tee For Desalination
Place of Origin CHINA
Brand Name Shangle
Certification ISO9001
Model Number stainless steel pipe fittings
Minimum Order Quantity MOQ500kg
Price Negotiable
Packaging Details In wooded cases or pallets,or as for clients requirement
Delivery Time 7-15 working days after receiving payment
Payment Terms L/C, T/T
Supply Ability 9999

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Port Ningbo Size 1/8”NB To 4”NB (Socketweld & Screwed-Threaded)
Type Screwed-Threaded Fittings Package Seaworthy Standard Package
Price Terms FOB,CIF,CFR,EXW Shape Equal
Connection Female/Male Degree 45°，90°，180°
Highlight

Super Duplex Steel Buttweld Fittings

,

2 Inch Butt Weld Equal Tee

,

Sch80 Butt Weld Equal Tee
Leave a Message
Product Description

ASTM A815 WP32760-S Super Duplex Steel Equal Tee Butt Weld Fittings For Desalination

Wenzhou Shangle Steel Co., Ltd. (Shangle) founded in 2017,is a comprehensive company integrating industry and trade.As a leading supplier of stainless steel products in Wenzhou, it has a wide range of products in stock that have been rigorously tested and are ready to be shipped.



Description :

ASTM A815 WPS32760 Super Duplex Steel Pipe Fittings have high tensile strength, durability, and excellent corrosion resistive property. ASTM A815 UNS S32760 Super Duplex Pipe Fittings can be used in various industries which operate in extreme environments and temperatures.

ASTM A815 WP-S UNS S32760 Super Duplex Stainless Steel Fittings are used in applications like heat exchangers, pressure vessels, desalination plants, power industry, etc. UNS S32760 Super Duplex Stainless Steel Butt weld Fittings can withstand the uniform corrosion conditions. Due to their good strength, excellent corrosion resistance, and good durability, UNS S32760 Super Duplex Steel Pipe Fittings can be used in various industries, including oil & gas, marine, construction, and aerospace applications.



Specification:

Specification ASTM A815 UNS S32760
Type Butt Weld, Welded, Seamless
Thickness SCH 5S - SCHXXS
Dimension ANSI B16.28, MSS-SP-43 Type A, JIS B2312, ANSI B16.9, MSS-SP-43 Type B, JIS B2313
Fittings Standard DIN, EN, ISO, JIS, NPT
Connection Type Threaded/ Weld/ Flange/ Clamp End / End Bell
ASME B16.9 Type Elbow, Tee, Reducer, Cap, Stub End, Bend, Adapter, Wye, Cross,
Class Class 150, Class 300, Class 600, Class 1500, Class 2500.
Size 1/2” to 48”



Chemical Composition:

C Mn P S Si Cr Ni Mo N W
0.03 max 1.00 max 0.03 max 0.01 max 1 max 24-26 4.5-6.5 3-4 0.25 0.08-0.20



Mechanical Properties:

Density Yield Strength (0.2%Offset) Tensile Strength Melting Point Elongation
7800 kg/m3 80Ksi, 550MPa 116Ksi, 800MPa 1350 °C (2460 °F) 15 %



Applications:

Sugar Industry

Fertilizers Industry

Oil & Gas Industry

Chemical Industry

Gas Processing Industry

Petrochemical Industry

Power Generation Industry

Food Processing Industry

Offshore Platforms





Material

Stainless steel: A403 WP304/304L, A403 WP316/316L, A403 WP321, A403 WP310S,

A403 WP347H, A403 WP316Ti, A403 WP317, 904L, 1.4301,1.4307,1.4401,1.4571,

1.4541, 254Mo and etc.

Duplex stainless steel: UNS31803, 2205, UNS32205, UNS31500, UNS32750 ,

UNS32760, 1.4462,1.4410,1.4501 and etc.

Nickel alloy: inconel600, inconel625, inconel690, incoloy800, incoloy 825, incoloy 800H,

C22, C-276,Monel400, Alloy20 etc.
